The LMH-CU is conveniently paired with a top-of-the-line LD400 Universal Laser Detector and heavy-duty rod clamp. Recommended working range of up to 300m dia. with Laser Detector.

Levels itself via electronic sensors interfaced with motors, eliminating the need for re-leveling or re-checks. ADS, Anti Drift System sensor provides peace of mind when working on a busy site. If the laser is altered due to tripod movement or an accidental bump, the operator is instantly alerted.

Features:

  Single Beam Offers 600 RPM Rotation for Optimal Use with Detector or Depth Sensor
  Anti-Drift System to Signal Operator When Unit is Moved Out of Position Automatic/Manual
   Mode
  No Bubble Required – Wide Self-Leveling Range of ±3º (1º per Second in Horizontal)
  Low Battery Indicator So You Don’t Run Out of Power at the Wrong Time
  Heavy Duty Glass Enclosed Beacon and Durable Sealed Housing is Water and Dust-
   Resistant (IP54) to Ensure Years of Dependable Operation
  Pro Grade – Motorized, Electronic Horizontal Self-Leveling



technical data	CST/berger LMH-CU
Range	up to 300 m radius with laser receiver
Self leveling accuracy	± 2.4 mm at 30 m (±3/32" at 100 ft) (0.08mm/m)
Automatic self levelling laser	horizontal
Self levelling range	± 3°
Rotation speed	600 rpm
Scanning angle	n/a
Wall mount bracket	n/a
Laser Diode	650nm
Battery types	rechargeable battery pack (NiMH)
Protection class	IP 54, dust and splash-proof
Warranty	2 Years

your shipment will include:
 1 no. CST/berger 57-LMH-CU Horizontal  Rotating Laser
 1 no. LD400 Laser Receiver & Bracket
 1 no. NiMH Battery Pack & Charger
 1 no. Protective Hard Case
 1 no. 24 Month Warranty
